LUUS Professional 2 Basket Single V-Pan Fryer 450mm - FV-45

Easy to clean V-pan design with cool zone
High performance burners and recovery rates
Includes pilot, FFD, piezo and high temp cutout
30kg/h production rate
20 litre oil capacity
Cabinet design with internal fryer controls
Supplied with 2 fryer baskets
Modular Professional series design
24 month Platinum Warranty
Easy control/burner access for servicing

V-Pan Fryer

100MJ/h jet burner with pilot, FFD and piezo ignition
Mechanically controlled thermostat
Thermostat temperature range 100 - 200 C
High temperature cut-out safety mechanism
1.5mm stainless steel tank
20 litre tank capacity
Includes 2 stainless steel fryer baskets
0.9mm stainless steel perforated fish/base plate
Tank drainage valve at bottom front of unit

Overall Construction

Heavy duty construction
Constructed 0.9mm stainless steel door
High density Fiberfrax Durablanket insulation around tank
Welded 1.2mm stainless steel front hob
Front and side panels 0.9mm stainless steel
Splashback 1.2 mm stainless steel
Includes stainless steel legs with 55mm adjustable range

Dimensions

450mm x 800mm x 1100mm H
Working height 900mm
Weight 72kg
Packed dimensions 640mm x 860mm x 1260mm H
Packed weight 92kg

Connections

Gas 3/4 BSP male
Gas 225mm from right, 50mm from rear, 210mm from floor
In-built gas regulator (specify Nat or LP on order)
Drain 1 1/4 BSP male
Drain 225mm from left, 70mm from front, 385mm floor

Cleaning & Servicing

Easy access to all parts & components from front
V-pan easy-to-clean design
Rear basket support bar
Removable baskets and inserts
